Electrical Specifications |
|
|
頻率 |
698-960/1710-2700 MHz |
|
增益 |
8 dBi |
|
Horizontal Beam Width |
90 deg |
|
Vertical Beam Width |
55 deg |
|
駐波比 |
700-750MHz:VSWR<=2 750-2500MHz:VSWR<=2 |
|
阻抗 |
50 ohm |
|
最大功率 |
100 W |
|
Front to back radio |
>=15 dB |
|
Mechanical Specifications |
|
|
連接頭類型 |
Sma male |
|
尺寸 |
210x180x44 mm |
|
重量 |
0.5 kg |
|
Radome Material |
ABS |
|
天線溫度 |
-40-60 |
-------------------------------------------------------------------
