Electrcal Specifications |
|
|
頻率范圍 |
698~960 / 1710-2700MHz |
|
增益 |
9dBi |
|
極化 |
Vertical |
|
Horizontal Beam Width |
90° |
|
Vertical Beam Width |
60° |
|
Front to Back ratio |
≥18 dB |
|
駐波比 |
≤1.5 |
|
阻抗 |
50 Ω |
|
最大功率 |
100 W |
|
Lightning Protection |
Direct Ground |
|
Mechanical Specifications |
|
|
連接頭類型 |
N-K |
|
尺寸 |
300mm×210mm×65mm |
|
重量 |
1 kg |
|
Max Wind Speed |
60 m/s |
|
安裝柱直徑 |
φ55~φ105 |
|
溫度 |
-40℃~70℃ |
-------------------------------------------------------------------
